Mohamed M. Atalla (Arabic: محمد محمد عطاالله, Mohamed Mohamed Atalla; August 4, 1924 – December 30, 2009) was an Egyptian–American engineer, physical chemist, cryptographer, inventor and entrepreneur. His pioneering work in semiconductor technology laid the foundations for modern electronics. Most importantly, his invention of the MOS transistor (MOSFET) in 1959, along with his earlier surface passivation and thermal oxidation processes (the basis for silicon semiconductor technology such as the monolithic integrated circuit chip), revolutionized the electronics industry. He is also known as the founder of the data security company Atalla Corporation (now Utimaco Atalla), founded in 1972, which introduced the first hardware security module and was a pioneer in online security. He received the Stuart Ballantine Medal (now the Benjamin Franklin Medal in physics) and was inducted into the National Inventors Hall of Fame for his important contributions to semiconductor technology as well as data security.

Born in Port Said, Egypt, he was educated at Cairo University in Egypt and then Purdue University in the United States, before joining Bell Labs in 1949 and later adopting the more anglicized "John" or "Martin" M. Atalla as professional names. He made a series of breakthroughs in semiconductor technology during 1956–1962, starting with his development of the surface passivation and thermal oxidation processes (the basis for silicon semiconductor technologies such as the planar process and monolithic integrated circuit chips), followed by his invention of the MOSFET (with Dawon Kahng) in 1959, then the PMOS and NMOS fabrication processes, his proposal of the MOS integrated circuit chip in 1960, and the demonstration of nanolayer transistors and practical Schottky diodes. Atalla's pioneering work at Bell laid the foundations for modern electronics, the silicon revolution, and the Digital Revolution. The MOSFET in particular is the basic building block of modern electronics, and is considered to be possibly the most important invention in electronics. It is also the most widely manufactured device in history, and the US Patent and Trademark Office calls it a "groundbreaking invention that transformed life and culture around the world".

His invention of the MOSFET was initially overlooked at Bell, which led to him resigning from Bell and joining Hewlett-Packard (HP), founding its Semiconductor Lab in 1962 and then HP Labs in 1966, before leaving to join Fairchild Semiconductor, founding its Microwave & Optoelectronics division in 1969. His work at HP and Fairchild included further research on Schottky diodes, in addition to research on gallium arsenide (GaAs), gallium arsenide phosphide (GaAsP), indium arsenide (InAs) and light-emitting diode (LED) technologies, contributing to the development of high-frequency network analyzers, developing the first practical LED displays, and proposing LED optical readers.

He later left the semiconductor industry, and became an entrepreneur in cryptography, data security and cybersecurity. In 1972, he founded Atalla Corporation, and filed a patent for a remote PIN security system over telecommunications networks, a precursor to telephone banking, Internet security and e-commerce. In 1973, he released the first hardware security module, the "Atalla Box" which encrypted PIN and ATM messages, and went on to secure the majority of the world's ATM transactions. Atalla also launched an early online transaction processing security system in 1976 and the first network security processor (NSP) in 1979, and he later founded the Internet company TriStrata Security in the 1990s. In recognition of his work on the Personal Identification Number (PIN) system of information security management as well as cybersecurity, Atalla has been referred to as the "Father of the PIN" and as a pioneer of information security technology. He died in Atherton, California, on December 30, 2009.

Early life and education (1924–1949)[]

Mohamed Mohamed Atalla[2][3][4] was born in Port Said, Egypt.[5] He studied at Cairo University in Egypt, where he received his Bachelor of Science degree. He later went to the United States, to study mechanical engineering at Purdue University. There, he received his master's degree (MSc) in 1947 and his doctorate (PhD) in 1949, both in mechanical engineering.[5] His MSc thesis was "High Speed Flow in Square Diffusers" published in 1948,[6] and his PhD thesis was "High Speed Compressible Flow in Square Diffusers" published in January 1949.[3]

Bell Telephone Laboratories (1949–1962)[]

After completing his PhD at Purdue University, Atalla was employed at Bell Telephone Laboratories (BTL) in 1949.[7] In 1950, he began working at Bell's New York City operations, where he worked on problems related to the reliability of electromechanical relays,[8] and worked on circuit-switched telephone networks.[9] With the emergence of transistors, Atalla was moved to the Murray Hill lab, where he began leading a small transistor research team in 1956.[8] Despite coming from a mechanical engineering background and having no formal education in physical chemistry, he proved himself to be a quick learner in physical chemistry and semiconductor physics, eventually demonstrating a high level of skill in these fields.[10] He researched, among other things, the surface properties of silicon semiconductors and the use of silica as a protective layer of silicon semiconductor devices.[7] He eventually adopted the alias pseudonyms "Martin" M. Atalla or "John" M. Atalla for his professional career.[4]

Between 1956 and 1960, Atalla led a small team of several BTL researchers, including Eileen Tannenbaum, Edwin Joseph Scheibner and Dawon Kahng.[11] They were new recruits at BTL, like himself, with no senior researchers on the team. Their work was initially not taken seriously by senior management at BTL and its owner AT&T, due to the team consisting of new recruits, and due to the team leader Atalla himself coming from a mechanical engineering background, in contrast to the physicists, physical chemists and mathematicians who were taken more seriously, despite Atalla demonstrating advanced skills in physical chemistry and semiconductor physics.[10]

Despite working mostly on their own,[10] Atalla and his team made significant advances in semiconductor technology.[11] According to Fairchild Semiconductor engineer Chih-Tang Sah, the work of Atalla and his team during 1956–1960 was "the most important and significant technology advance" in silicon semiconductor technology,[11][12] including the history of transistors[13] and microelectronics.[14]

Surface passivation by thermal oxidation[]

See also: Planar process, p–n junction isolation, Integrated circuit, and Invention of the integrated circuit

An initial focus of Atalla's research was to solve the problem of silicon surface states. At the time, the electrical conductivity of semiconductor materials such as germanium and silicon were limited by unstable quantum surface states,[15] where electrons are trapped at the surface, due to dangling bonds that occur because unsaturated bonds are present at the surface.[16] This prevented electricity from reliably penetrating the surface to reach the semiconducting silicon layer.[7][17] Due to the surface state problem, germanium was the dominant semiconductor material of choice for transistors and other semiconductor devices in the early semiconductor industry, as germanium was capable of higher carrier mobility.[18][19]

He made a breakthrough with his development of the surface passivation process.[7] This is the process by which a semiconductor surface is rendered inert, and does not change semiconductor properties as a result of interaction with air or other materials in contact with the surface or edge of the crystal.[20] The surface passivation process was first developed by Atalla in the late 1950s.[7][21] He discovered that the formation of a thermally grown silicon dioxide (SiO2) layer greatly reduced the concentration of electronic states at the silicon surface,[21] and discovered the important quality of SiO2 films to preserve the electrical characteristics of p–n junctions and prevent these electrical characteristics from deteriorating by the gaseous ambient environment.[22] He found that silicon oxide layers could be used to electrically stabilize silicon surfaces.[23] He developed the surface passivation process, a new method of semiconductor device fabrication that involves coating a silicon wafer with an insulating layer of silicon oxide so that electricity could reliably penetrate to the conducting silicon below. By growing a layer of silicon dioxide on top of a silicon wafer, Atalla was able to overcome the surface states that prevented electricity from reaching the semiconducting layer. His surface passivation method was a critical step that made possible the ubiquity of silicon integrated circuits, and later became critical to the semiconductor industry.[7][17] For the surface passivation process, he developed the method of thermal oxidation, which was a breakthrough in silicon semiconductor technology.[24]

The surface passivation process was a breakthrough in silicon semiconductor research,[16][21][19] as it enabled silicon to surpass the conductivity and performance of germanium, and was the breakthrough that led to silicon replacing germanium as the dominant semiconductor material.[19][15] The process also laid the foundations for the monolithic integrated circuit chip, as it was the first time that high-quality silicon dioxide insulator films could be grown thermally on the silicon surface to protect the underlying silicon p-n junction diodes and transistors.[22] Before the development of integrated circuit chips, discrete diodes and transistors exhibited relatively high reverse-bias junction leakages and low breakdown voltage, caused by the large density of traps at the surface of single crystal silicon. Atalla's surface passivation process became the solution to this problem. He discovered that when a thin layer of silicon dioxide was grown on the surface of silicon where a p–n junction intercepts the surface, the leakage current of the junction was reduced by a factor from 10 to 100. This showed that the oxide reduces and stabilizes many of the interface and oxide traps. Oxide-passivation of silicon surfaces allowed diodes and transistors to be fabricated with significantly improved device characteristics, while the leakage path along the surface of the silicon was also effectively shut off.[14] His surface oxidation method provided a semiconductor surface that was insensitive to the environment.[8] This became a fundamental p–n junction isolation capability necessary for planar technology and integrated circuit chips.[14]

The surface passivation process is also known as the "Atalla passivation" technique.[25] Atalla first published his findings in BTL memos during 1957, before presenting his work at an Electrochemical Society meeting in 1958,[26][27] the Radio Engineers' Semiconductor Device Research Conference.[8] The semiconductor industry saw the potential significance of Atalla's surface oxidation method, with RCA calling it a "milestone in the surface field."[8] The same year, he made further refinements to the process with his colleagues Eileen Tannenbaum and Edwin Joseph Scheibner, before they published their results in May 1959.[12][28] According to Fairchild Semiconductor engineer Chih-Tang Sah, the surface passivation process developed by Atalla and his team "blazed the trail" that led to the development of the silicon integrated circuit.[14][12] Atalla's silicon transistor passivation technique by thermal oxide[29] was the basis for several important inventions in 1959: the MOSFET (MOS transistor) by Atalla and Dawon Kahng at Bell Labs, the planar process by Jean Hoerni at Fairchild Semiconductor, and the monolithic integrated circuit chip by Robert Noyce at Fairchild in 1959.[27][14][30] By the mid-1960s, Atalla's process for oxidized silicon surfaces was used to fabricate virtually all integrated circuits and silicon devices.[31] In addition to silicon semiconductor technology, the surface passivation process is also critical to solar cell[32] and carbon quantum dot technologies.[20]

MOS transistor (MOSFET)[]

See also: PMOS and NMOS
MOSFET Structure

The MOSFET was invented by Atalla with his colleague Dawon Kahng in 1959, based on Atalla's earlier surface passivation and thermal oxidation processes.

Building on his earlier pioneering research[33] on the surface passivation and thermal oxidation processes,[24] Atalla developed the metal–oxide–semiconductor (MOS) process.[7] Atalla then proposed that a field effect transistor–a concept first envisioned in the 1920s and confirmed experimentally in the 1940s, but not achieved as a practical device—be built of metal-oxide-silicon. Atalla assigned the task of assisting him to Dawon Kahng, a Korean scientist who had recently joined his group.[7] The led to the invention of the MOSFET (metal–oxide–semiconductor field-effect transistor) by Atalla and Kahng,[34][35] in November 1959.[8] Attalla and Kahng first demonstrated the MOSFET in early 1960.[36][37] With its high scalability,[38] and much lower power consumption and higher density than bipolar junction transistors,[39] the MOSFET made it possible to build high-density integrated circuit (IC) chips.[40]

There were originally two types of MOSFET logic, PMOS (p-type MOS) and NMOS (n-type MOS).[34] Both types were developed by Atalla and Kahng when they originally invented the MOSFET. They fabricated both PMOS and NMOS devices with a 20 µm and 10 µm metal gate lengths and 100 nm gate oxide thickness. However, only the PMOS devices were practical working devices at the time.[41]

MOS integrated circuit (MOS chip)[]

See also: Large-scale integration, Microprocessor, MOS memory, and VLSI

Atalla proposed the concept of the MOS integrated circuit chip in 1960. He noted that the MOS transistor's ease of fabrication made it useful for IC chips.[10] However, Bell Labs initially ignored MOS technology, as the company was not interested in ICs at the time.[10] Despite this, the MOSFET generated significant interest at RCA and Fairchild Semiconductor. Inspired by the first MOSFET demonstration by Atalla and Kahng in early 1960, researchers at RCA and Fairchild fabricated MOSFETs later that year, with Karl Zaininger and Charles Meuller fabricating a MOSFET at RCA, and Chih-Tang Sah building an MOS-controlled tetrode at Fairchild.[34] Atalla's concept of the MOS IC chip eventually became reality,[10] starting with an experimental MOS chip demonstrated by Fred Heiman and Steven Hofstein at RCA in 1962, after which MOS would become the dominant fabrication process for IC chips.[42] CMOS, which combined both PMOS and NMOS, was later developed by Chih-Tang Sah and Frank Wanlass at Fairchild in 1963.[43]

MOS revolution[]

See also: CMOS, Digital Revolution, Information Age, Microcomputer revolution, and Silicon Age

The MOSFET was the first truly compact transistor that could be miniaturised and mass-produced for a wide range of uses,[10] and went on to revolutionize the electronics industry.[44][45] The development of MOS technology, which was capable of increasing miniaturisation, eventually became the focus of RCA, Fairchild, Intel and other semiconductor companies in the 1960s, fuelling the technological and economic growth of the early semiconductor industry in California (centred around what later became known as Silicon Valley)[46] as well as Japan.[47]

The MOSFET forms the basis of modern electronics,[48] and is the basic element in most modern electronic equipment.[49] It is the most widely used semiconductor device in the world,[40][50] and the most widely manufactured device in history, with an estimated 13 sextillion MOS transistors manufactured as of 2018.[51][52] The MOSFET is central to the microelectronics revolution,[53] silicon revolution,[15][54] and microcomputer revolution,[55] and is the fundamental building block of modern digital electronics during the Digital Revolution, information revolution and Information Age.[56][57][58][59] It is used in a wide variety of electronics applications, such as computers, synthesizers,[17] communications technology, smartphones,[60] Internet infrastructure,[61][62][63] digital telecommunication systems, video games, pocket calculators, and digital wristwatches, among many other uses.[64] It has been described as the "workhorse of the electronics industry" due to being the building block of every microprocessor, memory chip and telecommunication circuit in use.[65] The US Patent and Trademark Office calls the MOSFET a "groundbreaking invention that transformed life and culture around the world".[60] The invention of the MOSFET by Atalla and Kahng has been credited as "the birth of modern electronics"[66] and is considered to be possibly the most important invention in electronics.[67]

Nanolayer transistor[]

See also: Nanoelectronics and History of nanotechnology

In 1960, Atalla and Kahng fabricated the first MOSFETs with a gate oxide thickness of 100 nm, along with metal gate lengths of 20 µm and 10 µm.[68] In 1962, Atalla and Kahng fabricated a nanolayer-base metal–semiconductor junction (M–S junction) transistor. This device has a metallic layer with nanometric thickness sandwiched between two semiconducting layers, with the metal forming the base and the semiconductors forming the emitter and collector. With its low resistance and short transit times in the thin metallic nanolayer base, the device was capable of high operation frequency compared to bipolar transistors. Their pioneering work involved depositing metal layers (the base) on top of single crystal semiconductor substrates (the collector), with the emitter being a crystalline semiconductor piece with a top or a blunt corner pressed against the metallic layer (the point contact). They deposited gold (Au) thin films with a thickness of 10 nm on n-type germanium (n-Ge), while the point contact was n-type silicon (n-Si).[69] Atalla resigned from BTL in 1962.[41]

Schottky diode[]

See also: Schottky diode and Metal–semiconductor junction

Extending their work on MOS technology, Atalla and Kahng next did pioneering work on hot carrier devices, which used what would later be called a Schottky barrier.[70] The Schottky diode, also known as the Schottky-barrier diode, was theorized for years, but was first practically realized as a result of the work of Atalla and Kahng during 1960–1961.[71] They published their results in 1962 and called their device the "hot electron" triode structure with semiconductor-metal emitter.[72] It was one of the first metal-base transistors.[73] The Schottky diode went on to assume a prominent role in mixer applications.[71]

Hewlett-Packard (1962–1969)[]

In 1962, Atalla joined Hewlett-Packard, where he co-founded Hewlett-Packard and Associates (HP Associates), which provided Hewlett-Packard with fundamental solid-state capabilities.[5] He was the Director of Semiconductor Research at HP Associates,[41] and the first manager of HP's Semiconductor Lab.[74]

He continued research on Schottky diodes, while working with Robert J. Archer, at HP Associates. They developed high vacuum metal film deposition technology,[75] and fabricated stable evaporated/sputtered contacts,[76][77] publishing their results in January 1963.[78] Their work was a breakthrough in metal–semiconductor junction[76] and Schottky barrier research, as it overcame most of the fabrication problems inherent in point-contact diodes and made it possible to build practical Schottky diodes.[75]

At the Semiconductor Lab during the 1960s, he launched a material science investigation program that provided a base technology for gallium arsenide (GaAs), gallium arsenide phosphide (GaAsP) and indium arsenide (InAs) devices. These devices became the core technology used by HP's Microwave Division to develop sweepers and network analyzers that pushed 20–40 GHz frequency, giving HP more than 90% of the military communications market.[74]

Atalla helped create HP Labs in 1966. He directed its solid-state division.[5]

LED display[]

See also: Light-emitting diode

He oversaw HP's research and development (R&D) on practical light-emitting diodes (LEDs) between 1962 and 1969, along with Howard C. Borden and Gerald P. Pighini. The first practical LED displays were built at Atalla's Semiconductor Lab.[79] They introduced the first commercial LED display in 1968.[80] It was one of the first uses of LED lamps, along with the LED indicator lamp introduced by Monsanto Company the same year.[81]

In February 1969, the same HP team under Borden, Pighini and Atalla introduced the HP Model 5082-7000 Numeric Indicator, the first LED device to use integrated circuit technology.[79] It was the first intelligent LED display, and was a revolution in digital display technology, replacing the Nixie tube and becoming the basis for later LED displays.[82]

Fairchild Semiconductor (1969–1972)[]

In 1969, he left HP and joined Fairchild Semiconductor.[70] He was the vice president and general manager of the Microwave & Optoelectronics division,[83] from its inception in May 1969 up until November 1971.[84] He continued his work on light-emitting diodes (LEDs), proposing they could be used for indicator lights and optical readers in 1971.[85] He later left Fairchild in 1972.[70]

Atalla Corporation (1972–1990)[]

He left the semiconductor industry in 1972, and began a new career as an entrepreneur in data security[70] and cryptography.[86] In 1972,[86] he founded Atalla Technovation,[87] later called Atalla Corporation, which dealt with safety problems of banking and financial institutions.[88]

Hardware security module[]

See also: Personal identification number and Automated teller machine

He invented the first hardware security module (HSM),[89] the so-called "Atalla Box", a security system that secures a majority of transactions from ATMs today. At the same time, Atalla contributed to the development of the personal identification number (PIN) system, which has developed among others in the banking industry as the standard for identification.

The work of Atalla in the early 1970s led to the use of high security modules. His "Atalla Box", a security system which encrypts PIN and ATM messages, and protected offline devices with an un-guessable PIN-generating key.[90] He commercially released the "Atalla Box" in 1973.[90] The product was released as the Identikey. It was a card reader and customer identification system, providing a terminal with plastic card and PIN capabilities. The system was designed to let banks and thrift institutions switch to a plastic card environment from a passbook program. The Identikey system consisted of a card reader console, two customer PIN pads, intelligent controller and built-in electronic interface package.[91] The device consisted of two keypards, one for the customer and one for the teller. It allowed the customer to type in a secret code, which is transformed by the device, using a microprocessor, into another code for the teller.[92] During a transaction, the customer's account number was read by the card reader. This process replaced manual entry and avoided possible key stroke errors. It allowed users to replace traditional customer verification methods such as signature verification and test questions with a secure PIN system.[91]

A key innovation of the Atalla Box was the key block, which is required to securely interchange symmetric keys or PINs with other actors of the banking industry. This secure interchange is performed using the Atalla Key Block (AKB) format, which lies at the root of all cryptographic block formats used within the Payment Card Industry Data Security Standard (PCI DSS) and American National Standards Institute (ANSI) standards.[93]

Fearful that Atalla would dominate the market, banks and credit card companies began working on an international standard.[90] Its PIN verification process was similar to the later IBM 3624.[94] Atalla was an early competitor to IBM in the banking market, and was cited as an influence by IBM employees who worked on the Data Encryption Standard (DES).[87] In recognition of his work on the PIN system of information security management, Atalla has been referred to as the "Father of the PIN"[5][95][96] and as a father of information security technology.[97]

The Atalla Box protected over 90% of all ATM networks in operation as of 1998,[98] and secured 85% of all ATM transactions worldwide as of 2006.[99] Atalla products still secure the majority of the world's ATM transactions, as of 2014.[89]

Online security[]

In 1972, Atalla filed U.S. patent 3938091 for a remote PIN verification system, which utilized encryption techniques to assure telephone link security while entering personal ID information, which would be transmitted as encrypted data over telecommunications networks to a remote location for verification. This was a precursor to telephone banking, Internet security and e-commerce.[87]

At the National Association of Mutual Savings Banks (NAMSB) conference in January 1976, Atalla announced an upgrade to its Identikey system, called the Interchange Identikey. It added the capabilities of processing online transactions and dealing with network security. Designed with the focus of taking bank transactions online, the Identikey system was extended to shared-facility operations. It was consistent and compatible with various switching networks, and was capable of resetting itself electronically to any one of 64,000 irreversible nonlinear algorithms as directed by card data information. The Interchange Identikey device was released in March 1976. It was one of the first products designed to deal with online transactions, along with Bunker Ramo Corporation products unveiled at the same NAMSB conference.[92] In 1979, Atalla introduced the first network security processor (NSP).[100]

In 1987, Atalla Corporation merged with Tandem Computers. Atalla went into retirement in 1990.

As of 2013, 250 million card transactions are protected by Atalla products every day.[86]

TriStrata Security (1993–1999)[]

It was not long until several executives of large banks persuaded him to develop security systems for the Internet to work. They were worried about the fact that no useful framework for electronic commerce would have been possible at that time without innovation in the computer and network security industry.[5] Following a request from former Wells Fargo Bank president William Zuendt in 1993, Atalla began developing a new Internet security technology, allowing companies to scramble and transmit secure computer files, e-mail, and digital video and audio, over the internet.[95]

As a result of these activities, he founded the company TriStrata Security in 1996.[101] In contrast to most conventional computer security systems at the time, which built walls around a company's entire computer network to protect the information within from thieves or corporate spies, TriStrata took a different approach. Its security system wrapped a secure, encrypted envelope around individual pieces of information (such as a word processing file, a customer database, or e-mail) that can only be opened and deciphered with an electronic permit, allowing companies to control which users have access to this information and the necessary permits.[95] It was considered a new approach to enterprise security at the time.[5]

Later years and death (2000–2009)[]

Atalla was the chairman of A4 System, as of 2003.[5]

He lived in Atherton, California. Atalla died on December 30, 2009, in Atherton.[102]

Awards and honors[]

Atalla was awarded the Stuart Ballantine Medal (now the Benjamin Franklin Medal in physics) at the 1975 Franklin Institute Awards, for his important contributions to silicon semiconductor technology and his invention of the MOSFET.[103][104] In 2003, Atalla received a Distinguished Alumnus doctorate from Purdue University.[5]

In 2009, he was inducted into the National Inventors Hall of Fame for his important contributions to semiconductor technology as well as data security.[7] He was referred to as one of the "Sultans of Silicon" along with several other semiconductor pioneers.[37]

In 2014, the 1959 invention of the MOSFET was included on the list of IEEE milestones in electronics.[105] In 2015, Atalla was inducted into the IT History Society's IT Honor Roll for his important contributions to information technology.[106]

Despite the MOSFET enabling Nobel Prize winning breakthroughs such as the quantum Hall effect[107] and the charge-coupled device (CCD),[108] there was never any Nobel Prize given for the MOSFET itself.[109] In 2018, the Royal Swedish Academy of Sciences which awards the science Nobel Prizes acknowledged that the invention of the MOSFET by Atalla and Kahng was one of the most important inventions in microelectronics and in information and communications technology (ICT).[110]

In 2023, Purdue University founded a new research institute named after him, the Atalla Institute for Advanced System Integration and Packaging (ASIP). According to Purdue University:[111]

The Atalla Institute for Advanced System Integration and Packaging (ASIP) will honor Purdue graduate Martin (John) M. Atalla, known as the co-inventor of the silicon MOSFET (metal-oxide-semiconductor field-effect transistor), one of the most widely used types of integrated circuits in microchips. With an estimated 10^22 silicon MOSFETs made so far and many more to come, it is the most manufactured invention in history. Atalla’s work led to the chips that make many aspects of daily life possible today.

“The work of Atalla and his team at Bell Labs led to the demonstration of the first silicon MOSFET in 1959 and blazed the trail for modern integrated circuit chips,” said Mark Lundstrom, Purdue’s chief semiconductor officer. “Our students and faculty can now honor his name by continuing to further his work.”
